Electronic Pressure Switch
The Electronic Pressure Switch is a high-accuracy, shock-resistant device with digital display, analog output, and solid-state relay for real-time industrial monitoring.
Read More
Pressure Switch
Electronic Pressure Switch
The Electronic Pressure Switch is an intelligent device with high-accuracy pressure measurement, digital display, and control, offering shock resistance, wide adjustable range, analog output, and solid-state relay for real-time industrial monitoring and automation.
Measurement Range: -0.1 ~ 0 ~ 60 MPa
Pressure Type: Gauge Pressure, Negative Pressure, Absolute Pressure
Accuracy Class: ≤ 0.5%
Protection Class: IP65 / IP54 (standard)
Medium Temperature: -40℃ ~ 350℃
Environmental Temperature: -20℃ ~ 70℃
Supply Voltage: 24 VDC / 220 VAC
Contact Material: Stainless steel (304 / 316L)
Description
Overview of Electronic Pressure Switch
The Electronic Pressure Switch is an intelligent device that integrates pressure measurement, digital display, and control, offering high accuracy, wide adjustable range, and excellent shock resistance. Designed for long service life and simple operation, it provides analog signal output and solid-state relay control, making it ideal for real-time monitoring and automation in industrial applications.
Features of Electronic Pressure Switch
Multi-level pressure setting to meet various digital control requirements
Output signal configurable as Normally Open (NO) or Normally Closed (NC)
4-digit high-brightness LED display for clear pressure indication
Supports up to 4 switching outputs with optional analog signal output
Adjustable switching points from zero to full scale
Compact design with long service life, high reliability, and stable operation
High accuracy, shock-resistant, and suitable for harsh industrial environments
Wide pressure measurement range and versatile mounting options
Applications of Electronic Pressure Switch
Gases, liquids, oils, and other non-solid media
Building water supply systems and air compressor pressure control
Automation machinery and industrial equipment monitoring
Petroleum, chemical, metallurgy, power, and water supply industries
Industrial sites requiring gauge or absolute pressure measurement and control
Price of Electronic Pressure Switch
The price of the Electronic Pressure Switch varies depending on actual specifications and configuration.
For the latest quotation of ZINACA Instruments’ pressure switches, please contact us directly.
Electronic Pressure Switch OEM Service
ZINACA Instruments is a professional industrial instrumentation manufacturer.
We can customize reliable electronic pressure switches according to your process requirements and working conditions.
If you are looking for a Electronic Pressure Switch OEM Service, please contact us for cooperation.
Electronic Pressure Switch Manufacturer
As a leading electronic pressure switch manufacturer, ZINACA Instruments provides high-precision, durable, and reliable devices for a wide range of industrial applications worldwide.
Technical Specifications
| Type Parameters | Specification |
|---|---|
| Measurement Range | -0.1 ~ 0 ~ 60 MPa |
| Protection Class | IP65 / IP54 (standard) |
| Stability | ≤ 0.1% per year |
| Display Mode | 0.56" digital tube |
| Medium Temperature | -40℃ ~ 350℃ |
| Environmental Temperature | -20℃ ~ 70℃ |
| Mounting Threads | G1/4 (compact type), M20×1.5 (standard & explosion-proof type) |
| Accuracy Class | ≤ 0.5% |
| Pressure Type | Gauge Pressure, Negative Pressure, Absolute Pressure |
| Supply Voltage | 24 VDC / 220 VAC |
| Display Range | -1999 ~ 9999 |
| Relative Humidity | ≤ 80% |
| Contact Material | Stainless steel (304 / 316L) |
